Q2 2024 Feed mill – 10th of Ramadan City
Food, Beverage & Dairy
Steel silos and feeding systems for feed mills and food plants.
4 high-resolution photos
A feed mill needed raw-material silos and automatic feeding and conveying systems linking the silos to the grinding and mixing lines.
Strict defined criteria:
Outlet angles designed for each material’s flow properties.
Silo shells and conical hoppers fabricated from rolled plate.
Screw conveyors, belts and rotary feeders fabricated.
Site installation with motors and sensors wired into the controls.
Certified, documented engineering
ENGINEERING BOTTLENECKS
Some fine materials bridge and block the silo outlets.
The new systems had to tie into a line that was already running.
ENGINEERED RESOLUTION
Steep outlet angles with low-friction liners and air pads.
Tie-ins carried out during short weekly stops.
Send your materials list, engineering drawings or samples for immediate review by our engineers, who will define the best technical path and schedule.
Q2 2024
Feed mill – 10th of Ramadan City
Discuss a Similar Product
Technical Documentation & Operations Gallery
Strict defined criteria:
Food-safe surfaces in contact with the feed.
Certified, documented engineering
Calculated Outlets with Liners
