Q3 2022 Silo station – Damietta Port
Grain Storage & Handling
Steel structures and trusses for grain storage and handling stations.
4 high-resolution photos
A port silo station needed support structures and trusses for conveyor bridges and elevator towers, built for conveyor dynamic loads and coastal wind.
Strict defined criteria:
Full structural analysis of trusses and towers in SAP2000.
CNC cutting and drilling of every joint for an exact fit.
Full hot-dip galvanizing followed by a marine paint coat.
Crane erection with high-strength bolted connections.
Certified, documented engineering
ENGINEERING BOTTLENECKS
Port humidity and salt attack unprotected steel within months.
Conveyor bridges more than 40 m up, above an operating station.
ENGINEERED RESOLUTION
Hot-dip galvanizing plus marine paint to multiply the protection life.
Bridges assembled whole on the ground and lifted in one piece to limit work at height.
Send your materials list, engineering drawings or samples for immediate review by our engineers, who will define the best technical path and schedule.
Q3 2022
Silo station – Damietta Port
